JA Solar JAM72S30GR

570W 575W 580W 585W 590W 595W JA Deepblue 3.0 Series Half Cell Module. Assembled with 11BB PERC cells and gapless ribbon connection technology, the modules can offer higher output power with improved module efficiency, the reduction of cells gaps brings outstanding module appearance. The half-cell configurature makes less shading effect, lower risk of hot spot, as well as more reliable and stable power generation.

86 18961863192

sean@guanjisolar.com

Product Description

MECHANICAL DATA
Cell	Mono
Weight	27.3kg
Dimensions	2278±2mm1134±2mm30±1mm
Cable Cross Section Size	4mm²(IEC)，12 AWG(UL)
No. of cells	144(6*24)
J-Box	IP68, 3 diodes
Connector	QC 4.10-351/ MC4-EVO2A

ELECTRICAL DATE(STC)
Rated Maximum Power(Pmax)[W]	540	545	550	555	560	565
Power Tolerance	0~+5W
Open Circuit Voltage(Voc) [V]	49.6	49.75	49.9	50.02	50.15	50.28
Maximum Power Voltage(Vmp) [V]	41.64	41.8	41.96	42.11	42.27	42.42
Short Circuit Current(lsc) [A]	13.86	13.93	14	14.07	14.14	14.21
Maximum Power Current(lmp) [A]	12.97	13.04	13.11	13.18	13.25	13.32
Module Efficiency[%]	20.90%	21.10%	21.30%	21.50%	21.70%	21.90%
